Category

Specification

Model

EP-UPS2000UC13OR

Capacity

2,000 VA / 1,800 W

Topology

Online Double Conversion

Phase

Single phase with ground (1:1)

Output Power Factor

0.9

Input Nominal Voltage

200 / 208 / 220 / 230 / 240 Vac

Input Operating Voltage Range

110–300 Vac (load dependent)

Input Frequency Range

40–70 Hz

Input Power Factor

0.99

Output Voltage

208 / 220 / 230 / 240 Vac (selectable)

Output Voltage Regulation

±1%

Output Frequency

50/60 Hz ±1 Hz (auto-sensing)

Output Waveform

Pure Sine Wave

Transfer Time

Zero (AC to Battery)

Efficiency (AC Mode)

Up to 91%

Efficiency (Battery Mode)

Up to 87%

Battery Type

12V / 9Ah Sealed Lead-Acid (Maintenance-free)

Number of Batteries

4

Battery Voltage

54.8 Vdc nominal

Recharge Time

4 hours to 90%

Outlets

8 × IEC C13

Display

LCD Panel

Communication Ports

USB + RS232 (SNMP optional)

Operating Temperature

0–40°C

Noise Level

<50 dBA

Dimensions (W × D × H)

440 × 460 × 86.5 mm (2U Rack/Tower)

Net Weight

Approx. 19.1 kg

Warranty

2 years (1 year on batteries)
