| Category | Specification |
|---|---|
| Model | UAP-AC-M-PRO |
| Wi-Fi Standard | 802.11a/b/g/n/ac (Wi-Fi 5) |
| Bands | Dual-band (2.4 GHz + 5 GHz) |
| MIMO | 3x3 MIMO on both bands (DL MU-MIMO) |
| Spatial Streams | 6 (3+3) |
| Max Data Rate | 2.4 GHz: 450 Mbps (BW40) 5 GHz: 1.3 Gbps (BW80) Aggregate: 1.75 Gbps |
| Antennas | 3x Internal Dual-Band Antennas, 8 dBi gain (MIMO-optimized omnidirectional) |
| Max TX Power | 22 dBm (both 2.4 GHz and 5 GHz) |
| Coverage Area | 185 m² (2,000 ft²) |
| Max Client Count | 250+ |
| Dimensions | 343.2 x 181.2 x 60.2 mm (13.51 x 7.13 x 2.37") |
| Weight | 633 g (1.40 lb) |
| Networking Interfaces | (2) 10/100/1000 Mbps Ethernet RJ45 ports |
| Buttons | Reset |
| Power Method | 802.3af PoE (Passive PoE) |
| Supported Voltage | 44–57V DC |
| Power Supply | 48V, 0.5A PoE Gigabit Adapter (included with single unit) |
| Max Power Consumption | 9W |
| Mounting | Wall / Pole (mounts included) |
| Pole Mount Diameter | 1–2.5" (25–63 mm) |
| Weatherproofing | IPX4 (outdoor rated) |
| Environment | Outdoor |
| Operating Temperature | -40 to 70° C (-40 to 158° F) |
| Certifications | CE, FCC, IC |
